Complete Tektronix 576 Curve Tracer system, including all the available test fixtures and 5 test adapters. It consists of:

	Tektronix 576 industry standard Curve Tracer with standard Test Fixture (Serial #B325903)
	Tektronix 176 Pulsed High Current Fixture for the 576 (Serial #B071355)
	Tektronix 172 Programmable Test Fixture for the 576 (Serial #B111499)
	Tektronix 576 Safety Box
	Tektronix Transistors Adapter for the 576 (013-0098-02
	Tektronix FETs Adapter for the 576 (013-0099-02)
	Tektronix Stud Diode Adapter for the 576 (013-0110-00)
	Tektronix TO-220 Transistor Adapter for the 576 (013-0138-01)
	Tektronix TO-3 Transistor Adapter for the 576 (013-0100-01)
	Original Tektronix Service Manual for the 576
	Original Tektronix Service Manual for the 178
	Original Tektronix Service Manual for the 172



The central instrument, the Tektronix 576 Curve Tracer, has a high serial number, includes the parameter readout module (numeric display) and has a very sharp trace; no double peaking (which indicates a gassy CRT). The case is in excellent condition and all knobs and dials are intact and operate properly.

The Tektronix 576 Curve Tracer delivers up to 220 watts peak on the collector supply to the device under test. With the 176 High-Current Fixtures, pulsed collector operation up to 200 amps peak is possible.

Read more about the Tektronix 576 specifications!

All items are in excellent working condition.

This collection is located in the Pacific Northwest and we strongly prefer a local buyer since shipping the heavy and delicate 576 is not easy.

A Tektronix Scope Cart is also available for this 576 but that is a pickup only item.

Paypal accepted. Call (503) 410-9850 or email:
